Features

• Mechanical clutch increases user control and protection
• Electronic variable speed switch for total control
• Impact-stop for drilling in wood, ceramic, steel and screwdriving applications
• Ideal for drilling large anchor, fixing and through holes in concrete and masonry from 6 to 32 mm in diameter
• Rotation-stop for light chiselling applications, render and tile removal
• Optimized power to weight ratio good power in light weight package
• Large hammer mechanism construction guarantees longer tool life and superior performance
• Active vibration control system incorporating a floating rear handle to reduce vibratio



  Technical Information

  Specification	Details
  Bit Type	SDS Plus
  Power Source	Corded
  Voltage	220V
  Chuck Capacity	32 mm
  Power Input	1000W
  Operation Modes	Hammering / Rotation / Hammering with Rotation
  Max. Impact Energy	4.9 J
  Impact Energy (EPTA 05/2009)	4.2 J
  No Load Speed	0–820 RPM
  Blows per Minute	0–4700 bpm
  Optimum Drilling Capacity (Concrete)	6–22 mm
  Max. Drilling Capacity (Concrete)	32 mm
  Max. Drilling Capacity (Core Bit)	100 mm
  Max. Drilling Capacity (Wood)	32 mm
  Max. Drilling Capacity (Metal)	13 mm
  Weight	4.2 kg
  Length × Height	370 × 250 mm
  Vibration Level	8.2 m/s²
